ASUS TUF GAMING B760-PLUS WIFI DDR5 ATX Motherboard

Category: Non classé

Overview OF The ASUS TUF GAMING B760-PLUS WIFI

The ASUS TUF GAMING B760-PLUS WIFI is a durable and performance-oriented ATX motherboard designed for Intel® LGA1700 processors, supporting 14th, 13th, and 12th Gen Intel® Core™, Pentium® Gold and Celeron® CPUs. Built with military-grade components and a robust thermal design, this board delivers reliable power delivery, advanced connectivity including Wi-Fi 6 and 2.5 Gb Ethernet, and comprehensive cooling for gaming and high-performance systems.

Key Features

Intel® B760 Chipset & LGA1700 Socket – Compatible with latest Intel CPUs for powerful gaming and productivity builds.
DDR5 Memory Support – Four DIMM slots support up to 192 GB high-speed DDR5 modules with OptiMem II and XMP profiles.
PCIe 5.0 x16 Slot – Next-gen graphics card support with enhanced bandwidth.
Wi-Fi 6 & 2.5 Gb Ethernet – Fast, reliable networking for gaming and streaming.
USB 3.2 Gen 2×2 Type-C – Ultra-fast data transfers up to 20 Gbps.
Comprehensive Cooling Controls – Fan Xpert 4 and Armoury Crate control for optimized system cooling.
TUF Components – Military-grade capacitors, SafeSlot Core+ PCIe reinforcement, and stainless steel back I/O for durability.

Specifications

Specification	Details
Model	ASUS TUF GAMING B760-PLUS WIFI
Chipset	Intel® B760
CPU Socket	LGA1700 (Intel® 14th/13th/12th Gen)
Memory	4 × DIMM, up to 192 GB DDR5
PCIe Slots	1 × PCIe 5.0 x16, 1 × PCIe 3.0 x16, 2 × PCIe 3.0 x1
Storage	3 × M.2 slots (PCIe 4.0 x4), 4 × SATA 6 Gb/s
LAN	Realtek 2.5 Gb Ethernet
Wi-Fi	Wi-Fi 6 (802.11ax)
USB (Rear I/O)	1 × USB 3.2 Gen 2×2 Type-C, 1 × USB 3.2 Gen 2, 2 × USB 3.2 Gen 1, 1 × USB 2.0
Graphics Outputs	1 × HDMI®, 1 × DisplayPort
Audio	Realtek 7.1-ch High-Definition Audio
Form Factor	ATX
RGB Headers	Addressable Gen 2 RGB + RGB strip header
Specs compiled from ASUS official sources and retailer data.

Conclusion

The ASUS TUF GAMING B760-PLUS WIFI is an excellent choice for gamers and PC builders who want durability, performance, and connectivity without breaking the budget. With support for next-gen Intel CPUs, high-speed DDR5 memory, PCIe 5.0 graphics, advanced cooling controls, and robust networking including Wi-Fi 6 and 2.5 Gb Ethernet, it provides a strong foundation for both gaming rigs and productivity systems.
